CÂMARAS USB E GIGE
Câmeras USB 3.0 eles são muito rápidos, têm resoluções até 12 Mpixel preto e branco ou de cor.
Velocidade máxima de 700 fps (imagens por segundo)
Também disponível com compensação térmica para medições metrológicas micrométricas.
Câmeras GIGE para instalações onde são necessárias longas distâncias com resoluções até 12 Mpixel preto e branco ou de cor.
Velocidade máxima de 350 fps (imagens por segundo)
Também disponível com compensação térmica para medições metrológicas micrométricas.
Câmeras Industriais USB 2.0 2 Mpixel preto e branco ou cores compactas em contentor M12 apenas 48 mm de comprimento com grau de protecção IP68.
Velocidade máxima de 30 fps.
iluminador LED intensidade ajustável integrado.
ESPECIFICAÇÕES TÉCNICAS
| HCT-VSC-31 | 1600 x 1200 | 2 MP | AR0261 | 30 | Mono / Cor | USB 2.0 |
| HCT-BAC-640-300gc | 640 x 480 | VGA | PYTHON 300 | 376 | Cor | GigE |
| HCT-BAC-640-300gm | 640 x 480 | VGA | PYTHON 300 | 376 | Mono | GigE |
| HCT-BAC-640-750uc | 640 x 480 | VGA | PYTHON 300 | 751 | Cor | USB 3.0 |
| HCT-BAC-640-750um | 640 x 480 | VGA | PYTHON 300 | 751 | Mono | USB 3.0 |
| HCT-BAC-640-90gc | 658 x 492 | VGA | ICX424 | 90 | Cor | GigE |
| HCT-BAC-640-90uc | 658 x 492 | VGA | ICX424 | 90 | Cor | USB 3.0 |
| HCT-BAC-640-120gc | 658 x 492 | VGA | ICX618 | 120 | Cor | GigE |
| HCT-BAC-640-90gm | 659 x 494 | VGA | ICX424 | 90 | Mono | GigE |
| HCT-BAC-640-90um | 659 x 494 | VGA | ICX424 | 90 | Mono | USB 3.0 |
| HCT-BAC-720-290gm | 720 x 540 | VGA | IMX287 | 293 | Mono | GigE |
| HCT-BAC-720-290gc | 720 x 540 | VGA | IMX287 | 293 | Cor | GigE |
| HCT-BAC-720-520uc | 720 x 540 | VGA | IMX287 | 520 | Cor | USB 3.0 |
| HCT-BAC-720-520um | 720 x 540 | VGA | IMX287 | 520 | Mono | USB 3.0 |
| HCT-BAC-750-30gc | 748 x 576 | CCIR | ICX409 | 30 | Cor | GigE |
| HCT-BAC-750-30gm | 752 x 580 | CCIR | ICX409 | 30 | Mono | GigE |
| HCT-BAC-780-75gc | 780 x 580 | CCIR | ICX415 | 75 | Cor | GigE |
| HCT-BAC-780-75gm | 782 x 582 | CCIR | ICX415 | 75 | Mono | GigE |
| HCT-BAC-800-200gc | 800 x 600 | CCIR | PYTHON 500 | 240 | Cor | GigE |
| HCT-BAC-800-200gm | 800 x 600 | CCIR | PYTHON 500 | 240 | Mono | GigE |
| HCT-BAC-800-510uc | 800 x 600 | CCIR | PYTHON 500 | 511 | Cor | USB 3.0 |
| HCT-BAC-800-510um | 800 x 600 | CCIR | PYTHON 500 | 511 | Mono | USB 3.0 |
| HCT-BAC-1280-60gc | 1280 x 1024 | 1,3 MP | EV76C560 | 60 | Cor | GigE |
| HCT-BAC-1300-60gc | 1280 x 1024 | 1,3 MP | EV76C560 | 60 | Cor | GigE |
| HCT-BAC-1300-60gmNIR | 1280 x 1024 | 1,3 MP | EV76C661 | 60 | Mono | GigE |
| HCT-BAC-1300-75gc | 1280 x 1024 | 1,3 MP | PYTHON 1300 | 88 | Cor | GigE |
| HCT-BAC-1300-75gm | 1280 x 1024 | 1,3 MP | PYTHON 1300 | 88 | Mono | GigE |
| HCT-BAC-1300-200uc | 1280 x 1024 | 1,3 MP | PYTHON 1300 | 203 | Cor | USB 3.0 |
| HCT-BAC-1300-200um | 1280 x 1024 | 1,3 MP | PYTHON 1300 | 203 | Mono | USB 3.0 |
| HCT-BAC-1280-60gm | 1282 x 1026 | 1,3 MP | EV76C560 | 60 | Mono | GigE |
| HCT-BAC-1300-60gm | 1282 x 1026 | 1,3 MP | EV76C560 | 60 | Mono | GigE |
| HCT-BAC-1300-22gc | 1294 x 964 | 1,3 MP | ICX445 | 22 | Cor | GigE |
| HCT-BAC-1300-30gc | 1294 x 964 | 1,3 MP | ICX445 | 30 | Cor | GigE |
| HCT-BAC-1300-30uc | 1294 x 964 | 1,3 MP | ICX445 | 30 | Cor | USB 3.0 |
| HCT-BAC-1300-22gm | 1296 x 966 | 1,3 MP | ICX445 | 22 | Mono | GigE |
| HCT-BAC-1300-30gm | 1296 x 966 | 1,3 MP | ICX445 | 30 | Mono | GigE |
| HCT-BAC-1300-30um | 1296 x 966 | 1,3 MP | ICX445 | 30 | Mono | USB 3.0 |
| HCT-BAC-1440-73gm | 1440 x 1080 | 1,6 MP | IMX273 | 73 | Mono | GigE |
| HCT-BAC-1440-73gc | 1440 x 1080 | 1,6 MP | IMX273 | 73 | Cor | GigE |
| HCT-BAC-1440-220uc | 1440 x 1080 | 1,6 MP | IMX273 | 220 | Cor | USB 3.0 |
| HCT-BAC-1440-220um | 1440 x 1080 | 1,6 MP | IMX273 | 220 | Mono | USB 3.0 |
| HCT-BAC-1600-60gc | 1600 x 1200 | 2 MP | EV76C570 | 60 | Cor | GigE |
| HCT-BAC-1600-60gm | 1602 x 1202 | 2 MP | EV76C570 | 60 | Mono | GigE |
| HCT-BAC-1600-20gc | 1624 x 1234 | 2 MP | ICX274 | 20 | Cor | GigE |
| HCT-BAC-1600-20uc | 1626 x 1234 | 2 MP | ICX274 | 20 | Cor | USB 3.0 |
| HCT-BAC-1600-20gm | 1626 x 1236 | 2 MP | ICX274 | 20 | Mono | GigE |
| HCT-BAC-1600-20um | 1626 x 1236 | 2 MP | ICX274 | 20 | Mono | USB 3.0 |
| HCT-BAC-1920-25gc | 1920 x 1080 | 2 MP | MT9P031 | 25 | Cor | GigE |
| HCT-BAC-1920-25gm | 1920 x 1080 | 2 MP | MT9P031 | 25 | Mono | GigE |
| HCT-BAC-1920-25uc | 1920 x 1080 | 2 MP | MT9P031 | 26 | Cor | USB 3.0 |
| HCT-BAC-1920-25um | 1920 x 1080 | 2 MP | MT9P031 | 26 | Mono | USB 3.0 |
| HCT-BAC-1920-40uc | 1920 x 1200 | 2.3 MP | IMX249 | 41 | Cor | USB 3.0 |
| HCT-BAC-1920-40um | 1920 x 1200 | 2.3 MP | IMX249 | 41 | Mono | USB 3.0 |
| HCT-BAC-1920-40gc | 1920 x 1200 | 2.3 MP | IMX249 | 42 | Cor | GigE |
| HCT-BAC-1920-40gm | 1920 x 1200 | 2.3 MP | IMX249 | 42 | Mono | GigE |
| HCT-BAC-1920-48gc | 1920 x 1200 | 2.3 MP | PYTHON 2000 | 50 | Cor | GigE |
| HCT-BAC-1920-48gm | 1920 x 1200 | 2.3 MP | PYTHON 2000 | 50 | Mono | GigE |
| HCT-BAC-1920-50gc | 1920 x 1200 | 2.3 MP | IMX174 | 50 | Cor | GigE |
| HCT-BAC-1920-50gm | 1920 x 1200 | 2.3 MP | IMX174 | 50 | Mono | GigE |
| HCT-BAC-1920-150uc | 1920 x 1200 | 2.3 MP | PYTHON 2000 | 150 | Cor | USB 3.0 |
| HCT-BAC-1920-150um | 1920 x 1200 | 2.3 MP | PYTHON 2000 | 150 | Mono | USB 3.0 |
| HCT-BAC-1920-155uc | 1920 x 1200 | 2.3 MP | IMX174 | 164 | Cor | USB 3.0 |
| HCT-BAC-1920-155um | 1920 x 1200 | 2.3 MP | IMX174 | 164 | Mono | USB 3.0 |
| HCT-BAC-2000-165uc | 2040 x 1086 | 2 MP | CMV2000 | 165 | Cor | USB 3.0 |
| HCT-BAC-2040-90uc | 2040 x 2046 | 4 MP | CMV4000 | 90 | Cor | USB 3.0 |
| HCT-BAC-2000-50gc | 2046 x 1086 | 2 MP | CMV2000 | 50 | Cor | GigE |
| HCT-BAC-2040-25gc | 2046 x 2046 | 4 MP | CMV4000 | 25 | Cor | GigE |
| HCT-BAC-2000-50gm | 2048 x 1088 | 2 MP | CMV2000 | 50 | Mono | GigE |
| HCT-BAC-2000-50gmNIR | 2048 x 1088 | 2 MP | CMV2000 NIR-enhanced | 50 | Mono | GigE |
| HCT-BAC-2000-165um | 2048 x 1088 | 2 MP | CMV2000 | 165 | Mono | USB 3.0 |
| HCT-BAC-2000-165umNIR | 2048 x 1088 | 2 MP | CMV2000 NIR-enhanced | 165 | Mono | USB 3.0 |
| HCT-BAC-2040-35gc | 2048 x 1536 | 3 MP | IMX265 | 36 | Cor | GigE |
| HCT-BAC-2040-35gm | 2048 x 1536 | 3 MP | IMX265 | 36 | Mono | GigE |
| HCT-BAC-2040-55uc | 2048 x 1536 | 3 MP | IMX265 | 55 | Cor | USB 3.0 |
| HCT-BAC-2040-55um | 2048 x 1536 | 3 MP | IMX265 | 55 | Mono | USB 3.0 |
| HCT-BAC-2040-120uc | 2048 x 1536 | 3 MP | IMX252 | 120 | Cor | USB 3.0 |
| HCT-BAC-2040-120um | 2048 x 1536 | 3 MP | IMX252 | 120 | Mono | USB 3.0 |
| HCT-BAC-2040-25gm | 2048 x 2048 | 4 MP | CMV4000 | 25 | Mono | GigE |
| HCT-BAC-2040-25gmNIR | 2048 x 2048 | 4 MP | CMV4000 NIR-enhanced | 25 | Mono | GigE |
| HCT-BAC-2040-90um | 2048 x 2048 | 4 MP | CMV4000 | 90 | Mono | USB 3.0 |
| HCT-BAC-2040-90umNIR | 2048 x 2048 | 4 MP | CMV4000 NIR-enhanced | 90 | Mono | USB 3.0 |
| HCT-BAC-2440-20gc | 2448 x 2048 | 5 DEPUTADOS | IMX264 | 23 | Cor | GigE |
| HCT-BAC-2440-20gm | 2448 x 2048 | 5 DEPUTADOS | IMX264 | 23 | Mono | GigE |
| HCT-BAC-2440-35uc | 2448 x 2048 | 5 DEPUTADOS | IMX264 | 35 | Cor | USB 3.0 |
| HCT-BAC-2440-35um | 2448 x 2048 | 5 DEPUTADOS | IMX264 | 35 | Mono | USB 3.0 |
| HCT-BAC-2440-75uc | 2448 x 2048 | 5 DEPUTADOS | IMX250 | 75 | Cor | USB 3.0 |
| HCT-BAC-2440-75um | 2448 x 2048 | 5 DEPUTADOS | IMX250 | 75 | Mono | USB 3.0 |
| HCT-BAC-2500-14gc | 2590 x 1942 | 5 DEPUTADOS | MT9P031 | 14 | Cor | GigE |
| HCT-BAC-2500-14uc | 2590 x 1942 | 5 DEPUTADOS | MT9P031 | 14 | Cor | USB 3.0 |
| HCT-BAC-2500-20gc | 2590 x 2048 | 5 DEPUTADOS | PYTHON 5000 | 21 | Cor | GigE |
| HCT-BAC-2500-20gm | 2590 x 2048 | 5 DEPUTADOS | PYTHON 5000 | 21 | Mono | GigE |
| HCT-BAC-2500-60uc | 2590 x 2048 | 5 DEPUTADOS | PYTHON 5000 | 60 | Cor | USB 3.0 |
| HCT-BAC-2500-60um | 2590 x 2048 | 5 DEPUTADOS | PYTHON 5000 | 60 | Mono | USB 3.0 |
| HCT-BAC-2500-14gm | 2592 x 1944 | 5 DEPUTADOS | MT9P031 | 14 | Mono | GigE |
| HCT-BAC-2500-14um | 2592 x 1944 | 5 DEPUTADOS | MT9P031 | 14 | Mono | USB 3.0 |
| HCT-BAC-3088-16gm | 3088 x 2064 | 6 MP | IMX178 | 16 | Mono | GigE |
| HCT-BAC-3088-16gc | 3088 x 2064 | 6 MP | IMX178 | 16 | Cor | GigE |
| HCT-BAC-3088-57um | 3088 x 2064 | 6 MP | IMX178 | 59 | Mono | USB 3.0 |
| HCT-BAC-3088-57uc | 3088 x 2064 | 6 MP | IMX178 | 59 | Cor | USB 3.0 |
| HCT-BAC-3800-10gc | 3840 x 2748 | 10 MP | MT9J003 | 10 | Cor | GigE |
| HCT-BAC-3800-10gm | 3840 x 2748 | 10 MP | MT9J003 | 10 | Mono | GigE |
| HCT-BAC-3800-14uc | 3840 x 2748 | 10 MP | MT9J003 | 14 | Cor | USB 3.0 |
| HCT-BAC-3800-14um | 3840 x 2748 | 10 MP | MT9J003 | 14 | Mono | USB 3.0 |
| HCT-BAC-4024-8gm | 4024 x 3036 | 12 DEPUTADOS | IMX226 | 8 | Mono | GigE |
| HCT-BAC-4024-8gc | 4024 x 3036 | 12 DEPUTADOS | IMX226 | 8 | Cor | GigE |
| HCT-BAC-4024-29um | 4024 x 3036 | 12 DEPUTADOS | IMX226 | 31 | Mono | USB 3.0 |
| HCT-BAC-4024-29uc | 4024 x 3036 | 12 DEPUTADOS | IMX226 | 31 | Cor | USB 3.0 |
| HCT-BAC-4096-11gm | 4096 x 2160 | 9 DEPUTADOS | IMX267 | 12 | Mono | GigE |
| HCT-BAC-4096-11gc | 4096 x 2160 | 9 DEPUTADOS | IMX267 | 12 | Cor | GigE |
| HCT-BAC-4096-30um | 4096 x 2168 | 9 DEPUTADOS | IMX267 | 32 | Mono | USB 3.0 |
| HCT-BAC-4096-30uc | 4096 x 2168 | 9 DEPUTADOS | IMX267 | 32 | Cor | USB 3.0 |
| HCT-BAC-4096-40um | 4096 x 2168 | 9 DEPUTADOS | IMX255 | 42 | Mono | USB 3.0 |
| HCT-BAC-4096-40uc | 4096 x 2168 | 9 DEPUTADOS | IMX255 | 42 | Cor | USB 3.0 |
| HCT-BAC-4112-8gm | 4096 x 3000 | 12 DEPUTADOS | IMX304 | 8 | Mono | GigE |
| HCT-BAC-4112-8gc | 4096 x 3000 | 12 DEPUTADOS | IMX304 | 8 | Cor | GigE |
| HCT-BAC-4112-20um | 4096 x 3000 | 12 DEPUTADOS | IMX304 | 23 | Mono | USB 3.0 |
| HCT-BAC-4112-20uc | 4096 x 3000 | 12 DEPUTADOS | IMX304 | 23 | Cor | USB 3.0 |
| HCT-BAC-4112-30um | 4096 x 3000 | 12 DEPUTADOS | IMX253 | 30 | Mono | USB 3.0 |
| HCT-BAC-4112-30uc | 4096 x 3000 | 12 DEPUTADOS | IMX253 | 30 | Cor | USB 3.0 |
| HCT-BAC-4600-7gc | 4608 x 3288 | 14 DEPUTADOS | MT9F002 | 7 | Cor | GigE |
| HCT-BAC-4600-10uc | 4608 x 3288 | 14 DEPUTADOS | MT9F002 | 10 | Cor | USB 3.0 |
